Perfection in Every Pass: Spectral and Sheen Evaluation for Paint and Coating Systems

Now picture a newly painted museum room. A wide accent wall is bathed in spotlights. A half-way point in the corridor, at the spot where the painter opened a second five-gallon bucket, cuts a faint diagonal line through the wall. One side has a warm creamy finish and the other is a little cold and green.

This visual difference spoils architecture designs and leads to costly claims of repainting. Paints and industrial coatings are actually liquid mixtures possessing a lot of complications. They mix organic coloring materials with inorganic extenders, resins, solvents and curing additives. Shade and sheen change in an instant with a slight change in grinding time, batch temp, or solvent evaporation.

It's a dangerous game to rely on human vision alone for grading paint batches. Wet paint will appear darker than dry paint film. Fluorescent lights in the factory can change the appearance of colors from what they would look like in natural light. Shade fidelity is the only way to be certain of it by objective spectral data from raw pigment slurry to final dry film. That's where 3nh precision measurement tools step in.

Raw Pigments and Mill Bases: Controlling Tinting Power in Liquid Formulations

The grinding mill is the starting point for the production of paint. Raw dry pigments are added to liquid vehicles to make high concentration mill bases. Too coarse a grind results in poor color strength in the paint. If too fine, the viscosity changes and the cost of raw materials skyrockets.

Raw pigments are assessed by colour chemists through tests of ability to disperse and tint. Labs determine the effectiveness of the pigment to colour the white reduction paste by mixing a small amount of mill base with the regular white reduction paste.

The absorption curves of liquid samples and drawdowns are plotted on a spectrophotometer. Transparent stains and clear varnishes are measured with benchtop instruments having liquid transmission cells. Reflectance measurement shows the actual color strength and tinting values for opaque pastes.

3nh bench top spectrophotometers give paint chemists an accurate spectral curve. In seconds, formulators can tweak the amount of pigment to get the desired tinting power without incurring the cost of over-pigmentation, and ensure even tinting strength from one batch of raw to the next.

Architectural Paints: Guaranteeing Batch Harmony for Interior and Exterior Finishes

Consumers' expectations are high for architectural paints. Homeowners and contractors want the same color of a can of wall paint purchased in May as they do in November. Furthermore, automated point-of-sale (POS) tinting dispensers in retail stores need to be able to provide the correct tinting colors, as they would be pre-mixed in the factory.

There are also different types of sheens for the decorative coatings, from dead flat, eggshell, satin, semi-gloss to high-gloss. Surface sheen changes perception of color. A matte wall paint is quite a bit lighter than a high-gloss enamel with the same pigment formula.

To address this, coating engineers use d/8 sphere geometry spectrophotometers that feature two measurement modes: SCI (Specular Component Included) and SCE (Specular Component Excluded).

In SCI mode, the total amount of pigment colour is measured, rather than the surface gloss and/or the texture of any walls. SCE mode is used to measure colors the same way as they would appear on flat or textured drywall.

For paint manufacturers, 3nh spectrophotometers offer a very stringent CIELAB tolerance for base paints and tinting colorants. Thousands of windows are checked for tint accuracy by quality control teams to avoid customer returns and job site disputes.

Industrial and Automotive Coatings: Managing Sheen, Powder Coats, and Metallic Effects

Industrial coatings need to be pleasing to the eye, and provide protection to metal, plastic and wood components from adverse weather, chemicals and physical damage. Consider farm machinery, metal roofing panels, appliance powder coats, and automobile body panels.

Coil coating lines are used to coat long steel sheets with liquid paint at high speed before bending them into appliances such as cabinets or roofing panels. Any change in oven baking temperature will effect the curing of the paint, both in shade and surface hardness.

Likewise, metallic or pearlescent car finishes are made with small flakes of aluminum or mica. These effect pigments shift colour according to the angle of the light. They add a flop effect from highlight to shadow.

Multi-angle gloss measurement is very important here. Surface sheen is what determines whether or not a powder coat is in spec. Typical gloss meters are designed to measure specular reflection at 20, 60 and 85 degrees. High gloss finishes are done with 20 degree optics, medium sheen coatings are measured at 60 degree setups and low gloss matte finishes are measured at 85 degree setups.

Industrial coaters have full control with 3nh multi-angle gloss meters and high precision spectrophotometers. Inspectors verify gloss variation and colour drift directly on the curing line without having to cut metal coils, thus saving on waste.

Hiding Power and Drawdown Testing: Quantifying Film Opacity on Test Charts

A good paint should cover the color of the wall with the minimum number of coats. When a yellow wall paint needs four coats to cover a dark primer, consumers gripe about coverage.

The hiding power (or contrast ratio) of a wet or dry paint film is the ability of the film to not let any light pass through it to the substrate below. Standard drawdown procedures are required for the test of hiding power. Precise applicator blades are used by quality inspectors to apply the paint in an even film on black and white drawdown test cards.

After curing of the paint film, a spectrophotometers are used to measure the reflectance on a black area of the card and to compare it with reflectance measured on a white area of the card. The contrast ratios are automatically worked out by software. A number of 98 percent or higher means complete hiding power.

The 3nh benchtop and handheld spectrophotometers come with built-in hiding power measurement routines. Drawdown cards are tested in seconds, allowing the formulator to balance out the high cost of titanium dioxide opacifiers with raw material budgets.

Field Audits and Production QC: Portable Spectrophotometers on the Spray Line

Quality control of paint cannot be contained within the central laboratory. Field inspectors, contract painters and factory line supervisors must have a mobile measurement tool to ensure that sprayed finishes are cured onsite and in spray booths.

A desktop instrument is too heavy to be carried by a field inspector when inspecting cured powder coat on an outdoor architectural aluminum extrusion. Their requirements are for ergonomic handheld devices that can withstand dusty factory conditions.

Portable spectrophotometers with camera view finders enable the operators to target small curved parts, metal joints and textured powder coats with pinpoint accuracy. Narrow window frames, door handles and metal trim require small measurement apertures for precise readings.

The 3nh handheld spectrophotometers are designed to be compact and portable, with a rugged build to stand up to harsh environments. Inspectors take the data of the spectrum directly on the shop floor, and immediately receive pass/fail information, which is displayed in clear colour on the screen.

Optimizing Coating Performance through 3nh Analytical Equipment

Paint and coatings manufacturing is a precision science operating on tight commercial margins. A single rejected batch of industrial coil coating or architectural paint leads to expensive disposal costs and ruined client relationships.

From raw pigment grinding and drawdown opacity checks to high-gloss industrial powder coats and architectural wall paints, 3nh optical measurement solutions deliver total control. Precision spectrophotometers, multi-angle gloss meters, and 3nh SQCX software remove guesswork from formulation, production, and quality assurance.

Flawless finishes build commercial trust. With 3nh precision instruments, coating manufacturers deliver rich, durable colors and flawless sheen on every single pass.
